HAAS VF14/40 CNC VMC, New 2024, Installed 2025

Brand
HAAS

Model
VF14/40

Type
Machining Centers, Vertical, (5-Axis or More)

Stock #
60596-SC

Year
2024

Request a Quote

Specifications

CNC Control	yes
Type of CNC Control	HAAS CNC
# Axis	5
Table Size	150" x 28"
Table Capacity	4000 pounds
X-Axis Travel	150 inches
Y-Axis Travel	40 inches
Z-Axis Travel	30 inches
Spindle Speed	15000
Spindle Motor	30 HP
Spindle Taper	40 Taper
Tool Changer Capacity	50
X-Axis Feedrate	360 IPM
Y-Axis Feedrate	360 IPM
Z-Axis Feedrate	360 IPM
X-Axis Rapid Traverse Rate	360 IPM
Y-Axis Rapid Traverse Rate	600 IPM
Z-Axis Rapid Traverse Rate	600 IPM
Coolant Thru Spindle	yes
Max Distance Spindle To Table Top	34 inches

1,000 PSI Through-Spindle Coolant + High Pressure Flood Coolant
4th & 5th Axis Drive
210 mm (8.27") Tilting 2 Axis Trunnion Rotary Table
