Giddings & Lewis 108” / 120” Live Spindle VTC

Brand
G & L

Model
517 Series

Type
Boring Mills, Vertical

Stock #
10799-I

Year
1993

Request a Quote

Specifications

Equipped With

Description

Product: Giddings & Lewis 108” / 120” Live Spindle VTC
Model: 517 Series
Stock #: 10799-I
Serial No.: 517-0006-93
Year: 1993

Specifications:


Table Diameter	108"
Swing Diameter (max.)	120"
Height Under Rail (max.)	72"
Table Speeds (2 gear ranges)	To 150 RPM
Rail Elevation Travel	28"
Ram Travel (Z Axis)	50"
Ram Travel (x Axis)	67" Left of Center 67.5" Right of Center
Live Spindle Speeds (2 gear ranges)	To 2,200 RPM
Side Head Ram Travel	32”
Side Head Vertical Travel	63.38”

Equipped With:

G&L 8000 CNC Control
108” Plain Table w/ 100 HP Table Drive
C Axis (360,000 Positions – Full Contouring)
Elevating Cross Rail w/ Programmable Height & Leveling
25 HP Live Spindle in Vertical Ram
-Coolant Thru Vertical Ram Live Spindle
30 Tool ATC for Vertical Ram
24 Tool ATC for Side Head
High Volume Flood Coolant System
Trabon Lubrication
Lubricool
Part & Tool Probe Capability
